| Característica | Detalle |
|---|
| Chipset | Intel B760 |
| Socket | LGA1700 |
| Compatibilidad CPU | Intel Core 12ª, 13ª y 14ª Gen, Pentium Gold y Celeron |
| Formato | Micro-ATX (243.84 × 243.84 mm) |
| Memoria RAM | 4 ranuras DDR4 |
| Capacidad máxima | 128 GB |
| Frecuencia RAM | Hasta 4800 MHz (OC) |
| Canales | Dual Channel |
| XMP | Compatible con Intel XMP |
Expansión
-
1 × PCIe 4.0 x16 (para tarjeta gráfica)
-
2 × PCIe 4.0 x1 (tarjetas adicionales)
Almacenamiento
-
2 × M.2 PCIe 4.0 x4 NVMe
-
4 × SATA III 6 Gb/s
-
Soporte RAID 0 / 1 / 5 / 10
Conectividad y puertos
Video (requiere CPU con gráficos integrados):
-
HDMI 1.4 (hasta 4K 30Hz)
-
DisplayPort 1.4 (hasta 4K 60Hz)
-
VGA (D-Sub)
Red:
-
LAN Gigabit Realtek RTL8111H
-
No incluye Wi-Fi integrado.
USB:
-
1 × USB 3.2 Gen2 Type-C (10 Gbps)
-
3 × USB 3.2 Gen1 Type-A (5 Gbps)
-
8 × USB 2.0 (entre traseros y frontales)
Audio
-
Codec Realtek ALC897
-
Audio HD de 7.1 canales
Extras
-
4 LEDs de diagnóstico EZ Debug LED.
-
Conector TPM 2.0.
-
Conector RGB de 12V.
-
Compatible con Windows 10 y Windows 11 de 64 bits
